Min.vertical feed:5 um
Equal thickness of the workpiece: 0.008/300mm
Surface roughness of the workpiece: Ra0.63

1. CNC slid driling head, can control the depth of hole, have the function of drilling blind hole, expandinghole, and chamfering.
2. PLC control system, LCD display
3. Programme based on windows, Auto CAD , and support lofting software TEKLA6 Auto chip-remowa system, cooling liquid are circular
4. The whole machine are integrated designed, don't need to lay the foundation

1. Equipped with automatic lubrication system and air conditioner for electric cabinet.
2. Equipped with automatic feeding systems, which will clamp and feed material into machine automatically.
3. PLC systems, programming based on WINDOWS, fast and convenient programming, and visual previewing.
4. Drilling units equip with famous brand spindle motor.

This PMD series machine is a gantry mobile CNC drilling milling machine. It is mainly used for drilling, tapping and milling of workpieces such as flanges, heat exchangers, tube sheets, and slewing supports. Carbide drills can be used for internal cooling high-speed drilling. Holes can also be drilled externally with a high-speed steel twist drill bit. The machining process is numerically controlled, the operation is very convenient, and the mass production of automation, high precision and multiple varieties can be realized.
